OpenGL brush renderer specifics. More...
#include <kanzi/core.ui/platform/graphics_backend/gl/gl_brush_renderer.hpp>
Public Member Functions | |
| GlBrushRenderer (Brush *brush, Node *node) | |
| Constructor. More... | |
| virtual | ~GlBrushRenderer () |
| Destructor. More... | |
| MaterialSharedPtr | acquireErrorMaterial () |
| Acquire error material for rendering. More... | |
 Public Member Functions inherited from kanzi::BrushRenderer | |
| virtual | ~BrushRenderer () |
| Destructor. More... | |
| void | updateRender (bool forceOpaque, bool translucencyHint) |
| Called from Node2D::updateRender(), prepare brush for rendering. More... | |
| void | updateRender (bool forceOpaque) |
| Default parameter override for updateRender(). More... | |
| void | updateRender () |
| Default parameter override for updateRender(). More... | |
| void | bind (Renderer3D &renderer) |
| Bind brush renderer for rendering. More... | |
| void | draw (Renderer3D &renderer, const Geometry &quad, const Matrix4x4 &transform) const |
| Draw a brush using given quad. More... | |
| void | draw (Renderer3D &renderer, const Geometry &quad, const Matrix3x3 &transform) const |
| Overload for draw a brush using given quad. More... | |
| void | restoreResources () |
| Restore resources after sleep. More... | |
| Brush * | getBrush () const |
| Access brush. More... | |
| unsigned int | getPropertyChangeCounter () const |
| Access property change counter. More... | |
| float | getRenderOpacity () const |
| Access opacity. More... | |
| void | setRenderOpacity (float opacity) |
| Set opacity to use for next attach. More... | |
| TextureSharedPtr | getContentTexture () const |
| Access content texture. More... | |
| void | setContentTexture (TextureSharedPtr texture) |
| Set a content texture. More... | |
| Node * | getNode () const |
| Access node. More... | |
| RenderMode | getRenderMode () const |
| Get currently selected render mode. More... | |
| bool | hasRenderMode () const |
| Tell if any (valid) render mode selection has been made. More... | |
| bool | hasOpaqueRenderMode () const |
| Tell if selected render mode is opaque. More... | |
Additional Inherited Members | |
| Public Types inherited from kanzi::BrushRenderer | |
| enum | RenderMode { RenderModeNone, RenderModeInvalid, RenderModeOpaqueNoContent, RenderModeTranslucentNoContent, RenderModeOpaque, RenderModeTranslucent } |
| Enum signifying currently selected render mode. More... | |
| Protected Member Functions inherited from kanzi::BrushRenderer | |
| BrushRenderer (Brush *brush, Node *node) | |
| Constructor. More... | |
| virtual void | drawOverride (Renderer3D &renderer, const Geometry &geometry, const Matrix4x4 &transform) const =0 |
| Draw a clip quad. More... | |
| virtual void | bindOverride (Renderer3D &renderer)=0 |
| BrushRenderer-specific bind implementation. More... | |
| virtual void | updateRenderOverride (bool forceOpaque, bool translucencyHint)=0 |
| BrushRenderer-specific opacity override implementation. More... | |
| virtual void | restoreResourcesOverride ()=0 |
| BrushRenderer-specific restore resources implementation. More... | |
| void | setRenderMode (RenderMode selection) |
| Set render mode. More... | |
| bool | isChangeCounterSame () const |
| Check if property change counter matches that of the brush. More... | |
| void | updateChangeCounter () |
| Update property change counter to match brush. More... | |
OpenGL brush renderer specifics.
|
inlinevirtual |
Destructor.
| MaterialSharedPtr kanzi::GlBrushRenderer::acquireErrorMaterial | ( | ) |
Acquire error material for rendering.
To be used when the assigned material applicable.
