Text Block 2D displays a small amount of text in 2D. More...
#include <kanzi/ui/node/text_block2d.hpp>
Public Member Functions | |
| KzcRectangle | getGlyphPosition (size_t index) const |
| Returns glyph rectangle of given index in layer space. More... | |
 Public Member Functions inherited from kanzi::TextBlockConceptImpl< Node2D, TextBlock2D > | |
| float | getFontSize () const |
| Gets the value of the FontSizeProperty. More... | |
| void | setFontSize (float value) |
| Sets the value of the FontSizeProperty. More... | |
| MaterialSharedPtr | getFontMaterial () const |
| Gets the value of the FontMaterialProperty. More... | |
| void | setFontMaterial (MaterialSharedPtr value) |
| Sets the value of the FontMaterialProperty. More... | |
| ColorRGBA | getFontColor () const |
| Gets the value of the FontColorProperty. More... | |
| void | setFontColor (ColorRGBA value) |
| Sets the value of the FontColorProperty. More... | |
| TextHorizontalAlignment | getTextHorizontalAlignment () const |
| Gets the value of the TextHorizontalAlignmentProperty. More... | |
| void | setTextHorizontalAlignment (TextHorizontalAlignment value) |
| Sets the value of the TextHorizontalAlignmentProperty. More... | |
| TextVerticalAlignment | getTextVerticalAlignment () const |
| Gets the value of the TextVerticalAlignmentProperty. More... | |
| void | setTextVerticalAlignment (TextVerticalAlignment value) |
| Sets the value of the TextVerticalAlignmentProperty. More... | |
| float | getLineSpacing () const |
| Gets the value of the LineSpacingProperty. More... | |
| void | setLineSpacing (float value) |
| Sets the value of the LineSpacingProperty. More... | |
| float | getCharacterSpacing () const |
| Gets the value of the CharacterSpacingProperty. More... | |
| void | setCharacterSpacing (float value) |
| Sets the value of the CharacterSpacingProperty. More... | |
| float | getFixedCharacterWidth () const |
| Gets the value of the FixedCharacterWidthProperty. More... | |
| void | setFixedCharacterWidth (float value) |
| Sets the value of the FixedCharacterWidthProperty. More... | |
| string | getOverflow () const |
| Gets the value of the OverflowProperty. More... | |
| void | setOverflow (string_view value) |
| Sets the value of the OverflowProperty. More... | |
| string | getText () const |
| Gets the value of TextProperty. More... | |
| void | setText (string value) |
| Sets the value of TextProperty. More... | |
| bool | isWordWrap () const |
| Gets the value of WordWrapProperty. More... | |
| void | setWordWrap (bool value) |
| Sets the value of WordWrapProperty. More... | |
| bool | isConstrainContentHeight () const |
| Gets the value of ConstrainContentHeightProperty. More... | |
| void | setConstrainContentHeight (bool value) |
| Sets the value of ConstrainContentHeightProperty. More... | |
| Vector2 | getHorizontalPadding () const |
| Gets the value of HorizontalPaddingProperty. More... | |
| void | setHorizontalPadding (Vector2 value) |
| Sets the value of HorizontalPaddingProperty. More... | |
| Vector2 | getVerticalPadding () const |
| Gets the value of VerticalPaddingProperty. More... | |
| void | setVerticalPadding (Vector2 value) |
| Sets the value of VerticalPaddingProperty. More... | |
| FontHintingPreference | getHintingPreference () const |
| Gets the value of HintingPreferenceProperty. More... | |
| void | setHintingPreference (FontHintingPreference hintingPreference) |
| Sets the value of HintingPreferenceProperty. More... | |
| KzcRectangle | getTextBounds () const |
| Get bounding rectangle for the text. More... | |
| Public Member Functions inherited from kanzi::Node2D | |
| virtual | ~Node2D () |
| ChildConstIterator | beginChildren () const |
| ChildConstIterator | endChildren () const |
| ChildConstReverseIterator | rbeginChildren () const |
| ChildConstReverseIterator | rendChildren () const |
| void | addChild (Node2DSharedPtr child) |
| Adds a child node. More... | |
| void | insertChild (size_t index, Node2DSharedPtr child) |
| Adds a child node for object node to given index. More... | |
| void | removeChild (const Node &child) |
| Removes child node. More... | |
| void | removeChild (size_t index) |
| Removes child node at specified index. More... | |
| void | removeAllChildren () |
| Removes all child nodes. More... | |
| Node2DSharedPtr | getChild (size_t index) const |
| Returns a child from given index from object node. More... | |
| size_t | getChildIndex (const Node &child) const |
| Returns the index of a child in an object node. More... | |
| bool | hasChild (const Node &child) const |
| Returns whether or not the child exists. More... | |
| size_t | getChildCount () const |
| Gets the number of children of the node. More... | |
| void | moveToBack () |
| Repositions the node to the beginning of its parent's children, so that it is drawn first. More... | |
| void | moveToFront () |
| Repositions the node to the end of its parent's children, so that it is drawn last. More... | |
| RenderType | getRenderType () const |
| Get render type. More... | |
| BrushSharedPtr | getBackgroundBrush () const |
| Gets value of BackgroundBrushProperty. More... | |
| void | setBackgroundBrush (BrushSharedPtr value) |
| Sets value of BackgroundBrushProperty. More... | |
| BrushSharedPtr | getCompositionBrush () const |
| Gets value of CompositionBrushProperty. More... | |
| void | setCompositionBrush (BrushSharedPtr value) |
| Sets value of CompositionBrushProperty. More... | |
| BrushSharedPtr | getForegroundBrush () const |
| Gets value of ForegroundBrushProperty. More... | |
| void | setForegroundBrush (BrushSharedPtr value) |
| Sets value of ForegroundBrushProperty. More... | |
| BrushRenderer * | getBackgroundBrushRenderer () const |
| Get background brush renderer. More... | |
| BrushRenderer * | getForegroundBrushRenderer () const |
| Get foreground brush renderer. More... | |
| BrushRenderer * | getCacheChildrenBrushRenderer () const |
| Access cache children brush renderer. More... | |
| BrushRenderer * | getCacheSelfBrushRenderer () const |
| Access cache self brush renderer. More... | |
| BrushRenderer * | getCompositionBrushRenderer () const |
| Access cache result brush renderer. More... | |
| SRTValue2D | getRenderTransformation () const |
| Gets the value of RenderTransformationProperty. More... | |
| void | setRenderTransformation (SRTValue2D value) |
| Sets the value of RenderTransformationProperty. More... | |
| SRTValue3D | getPerspectiveTransformation () const |
| Gets the value of PerspectiveTransformationProperty. More... | |
| void | setPerspectiveTransformation (SRTValue3D value) |
| Sets the value of PerspectiveTransformationProperty. More... | |
| void | render (Renderer3D &renderer, CompositionStack &compositionStack) |
| Render individual 2D node. More... | |
| NodeVisual2D * | getVisual () const |
| Access visual component. More... | |
| TextureSharedPtr | getRenderTarget () const |
| Gets value of RenderTargetProperty. More... | |
| void | setRenderTarget (TextureSharedPtr texture) |
| Sets value of RenderTargetProperty. More... | |
| TextureSharedPtr | getFinalCompositionTarget () const |
| Returns composition target combining all Node2D content. More... | |
| bool | hasCacheChildren () const |
| Tell if node should cache its children. More... | |
| bool | hasCacheChildrenCompositionTarget () const |
| Tell if node has cache children composition target. More... | |
| bool | isCacheChildrenValid () const |
| Tell if children cache is valid. More... | |
| void | resetCacheChildren () |
| Reset cached content for children. More... | |
| bool | hasCacheResult () const |
| Tell if node should cache its result. More... | |
| bool | hasFinalCompositionTarget () const |
| Tell if node has final composition target. More... | |
| bool | isCacheResultValid () const |
| Tell if children cache is valid. More... | |
| void | resetCacheResult () |
| Reset cached content for complete node content including itself and its children. More... | |
| bool | hasCacheSelf () const |
| Tell if node should cache itself. More... | |
| bool | hasCacheSelfCompositionTarget () const |
| Tell if node has cache children composition target. More... | |
| bool | isCacheSelfValid () const |
| Tell if children cache is valid. More... | |
| void | resetCacheSelf () |
| Reset cached content for node itself. More... | |
| CompositionManager * | getCompositionManager () const |
| Access composition manager. More... | |
| NodeCompositor2D * | getCompositor () const |
| Access compositor component. More... | |
| void | setAutoWidth () |
| Sets node to automatically determine width. More... | |
| void | setAutoHeight () |
| Sets node to automatically determine height. More... | |
| void | setAutoSize () |
| Sets node to automatically determine both width and height. More... | |
| void | setSize (float width, float height) |
| Sets size properties of the node. More... | |
| void | setLayoutSize (float width, float height) |
| Sets size properties of the node. More... | |
| SRTValue2D | getLayoutTransformation () const |
| Gets the value of LayoutTransformationProperty. More... | |
| void | setLayoutTransformation (SRTValue2D value) |
| Sets the value of LayoutTransformationProperty. More... | |
| Vector2 | getDesiredSize () const |
| Get desired size. More... | |
| void | setDesiredSize (Vector2 size) |
| Set desired size. More... | |
| Vector2 | getAllocatedSize () const |
| Get allocated size. More... | |
| void | setAllocatedSize (Vector2 allocatedSize) |
| Set allocated size. More... | |
| Vector2 | getActualSize () const |
| Get actual size. More... | |
| void | setActualSize (Vector2 actualSize) |
| Set actual size. More... | |
| void | setActualSize (float sizeX, float sizeY) |
| Set actual size. More... | |
| Matrix3x3 | getArrangeTransform () const |
| Get arrange transform. More... | |
| void | setArrangeTransform (Matrix3x3 transform) |
| Set arrange transform. More... | |
| void | layout (optional< Matrix3x3 > rootTransform) |
| Does layout pass starting from this node and iterating recursively all of its children. More... | |
| void | layout () |
| Does layout pass with no root transformation (identity). More... | |
| bool | measure (const Vector2 *availableSize, bool handleStretch) |
| Measure one node. More... | |
| virtual bool | measureRecursive () |
| Perform measure recursively. More... | |
| void | arrange () |
| Arrange one Node2D. More... | |
| void | extract () |
| Extract one Node2D. More... | |
| Matrix3x3 | getWorldTransform () const |
| Get world transform. More... | |
| bool | containsLocal (Vector2 point) const |
| Tell if a node area contains a point (defined in node's own space). More... | |
| optional< Vector2 > | containsGlobal (Vector2 point) const |
| Tell if a node area contains a point (defined in screen space). More... | |
| optional< Vector2 > | globalToLocal (Vector2 point) const |
| NodeSharedPtr | hitTest (Vector2 point) |
| Performs a hit test to a 2D node and all its child nodes. More... | |
| NodeSharedPtr | hitTest (Vector2 point, const Metaclass *type) |
| Performs a hit test to a 2D node and all its child nodes. More... | |
| NodeSharedPtr | hitTestIterate (Vector2 point, HitTestVisitor visitor, void *userData) |
| Recursively hit test nodes from this node downwards and call visitor function on nodes hit. More... | |
| virtual tuple< NodeSharedPtr, KzcRay, float > | hitTestContent (Vector2 point) |
| Default implementation of Node2D content hit test. More... | |
| template<typename T > | |
| shared_ptr< T > | hitTest (Vector2 point) |
| Wrapper for hitTest(Vector2), casts the return value. More... | |
| template<typename T > | |
| shared_ptr< T > | hitTest (Vector2 point, const Metaclass *type) |
| Wrapper for hitTest(Vector2, const Metaclass), casts the return value. More... | |
| virtual NodeSharedPtr | findAbstractChildOverride (string_view name) KZ_OVERRIDE |
| Node::findAbstractChildOverride() implementation. More... | |
| virtual VisitorResult | visitAbstractChildOverride (const Visitor &visitor, VisitorOrder order) KZ_OVERRIDE |
| Node::visitAabstractChild implementation. More... | |
| virtual bool | addAbstractChildOverride (NodeSharedPtr child) KZ_OVERRIDE |
| Node::addAbstractChildOverride() implementation. More... | |
| virtual size_t | getAbstractChildCountOverride () KZ_OVERRIDE |
| Node::getAbstractChildCountOverride() implementation. More... | |
| virtual NodeSharedPtr | getAbstractChildOverride (size_t index) KZ_OVERRIDE |
| Node::getAbstractChildOverride() implementation. More... | |
| virtual bool | removeAbstractChildOverride (Node &child) KZ_OVERRIDE |
| Node::removeAbstractChildOverride() implementation. More... | |
| bool | compositionRequiresAlpha () const |
| Tell if composition requires alpha. More... | |
| void | setCompositionRequiresAlpha (bool enabled) |
| Turn composition alpha requirement on or off. More... | |
| bool | compositionRequiresDepth () const |
| Tell if composition requires depth. More... | |
| void | setCompositionRequiresDepth (bool enabled) |
| Turn composition depth requirement on or off. More... | |
| bool | compositionRequiresStencil () const |
| Tell if composition requires stencil. More... | |
| void | setCompositionRequiresStencil (bool enabled) |
| Turn composition stencil requirement on or off. More... | |
| QuadDescription | getBackgroundQuad () const |
| Gets the background quad description. More... | |
| ClippingArea | getClippingArea () const |
| Get clipping area. More... | |
| float | getLayoutOpacity () const |
| Get opacity after propagation from layouting hierarchy. More... | |
| Matrix3x3 | getRenderQuadTransform () const |
| Gets transformation used to render the 2D node. More... | |
| bool | hasCenterClipArea () const |
| Tell if Node2D has the center clip area (the area of itself). More... | |
| bool | hasOutsideClipArea () const |
| Tell if Node2D has outside clipping area. More... | |
| bool | hasTranslucentForeground () const |
| Tell if Node2D foreground has translucency. More... | |
| void | setForegroundIsTranslucent (bool enabled) |
| Set foreground translucency status. More... | |
| void | setFinalCompositionRequested (bool enabled) |
| Turn composition request on or off. More... | |
| bool | isCompositionClearColorRequired () const |
| Indicates whether composition target requires color clear before rendering. More... | |
| bool | isClearColorAllowed () const |
| Indicates whether this Node2D is allowed and should clear the color buffer of its own composition target. More... | |
| void | setClearColorAllowed (bool enabled) |
| Set clear color allowed. More... | |
| bool | isRenderChildrenAllowed () const |
| Tell if rendering children is allowed. More... | |
| bool | isRenderSelfAllowed () const |
| Tell if render self is allowed. More... | |
| bool | isVisibleForHitTesting () const |
| Tell if Node2D is visible for hit testing. More... | |
| bool | requiresBackgroundBrushRendering () const |
| Tell if background brush rendering is required. More... | |
| bool | requiresForegroundBrushRendering () const |
| Tell if foreground brush rendering is required. More... | |
| bool | hasChildrenRequireExtract () const |
| Tell if children require extract flag is on. More... | |
| void | setChildrenRequireExtract (bool enabled) |
| Set children require extract flag. More... | |
| bool | requiresExtract () const |
| Tell if node requires extraction. More... | |
| void | setRequiresExtract (bool enabled) |
| Turn extract requirement on or off. More... | |
| bool | isSelfInCompositionTarget () const |
| Tell if node itself is going to get rendered into a composition target. More... | |
| Vector2 | getContentDesiredSize () const |
| Get size desired by content. More... | |
| Vector2 | getSecondPassDesiredSize () const |
| Get second pass desired size. More... | |
| Vector2 | getUserDesiredSize () const |
| Get size desired by user. More... | |
| Matrix3x3 | getPartialArrangeTransform () const |
| Get partial arrange transform. More... | |
| bool | isCompletelyClipped () const |
| Tell if node is completely clipped (and needs not be rendered). More... | |
| bool | isCompletelyTransparent () const |
| Tell if node is completely transparent. More... | |
| float | getAspectRatio () const |
| Gets the value of AspectRatioProperty. More... | |
| void | setAspectRatio (float value) |
| Sets the value of AspectRatioProperty. More... | |
| bool | isForceComposition () const |
| Gets the value of ForceCompositionProperty. More... | |
| void | setForceComposition (bool value) |
| Sets the value of ForceCompositionProperty. More... | |
| Node2D::ForegroundHint | getForegroundHint () const |
| Gets the value of ForegroundHintProperty. More... | |
| void | setForegroundHint (Node2D::ForegroundHint value) |
| Sets the value of ForegroundHintProperty. More... | |
| bool | isCacheChildren () const |
| Gets the value of CacheChildrenProperty. More... | |
| void | setCacheChildren (bool value) |
| Sets the value of CacheChildrenProperty. More... | |
| bool | isCacheResult () const |
| Gets the value of CacheResultProperty. More... | |
| void | setCacheResult (bool value) |
| Sets the value of CacheResultProperty. More... | |
| bool | isCacheSelf () const |
| Gets the value of CacheSelfProperty. More... | |
| void | setCacheSelf (bool value) |
| Sets the value of CacheSelfProperty. More... | |
| bool | isOffscreenRendering () const |
| Gets the value of OffscreenRenderingProperty. More... | |
| void | setOffscreenRendering (bool value) |
| Sets the value of OffscreenRenderingProperty. More... | |
| bool | isDisableRenderTargetClear () const |
| Gets the value of DisableRenderTargetClearProperty. More... | |
| void | setDisableRenderTargetClear (bool value) |
| Sets the value of DisableRenderTargetClearProperty. More... | |
| Node2D::PixelFormat | getPixelFormat () const |
| Gets the value of PixelFormatProperty. More... | |
| void | setPixelFormat (Node2D::PixelFormat value) |
| Sets the value of PixelFormatProperty. More... | |
| bool | isRenderSelf () const |
| Gets the value of RenderSelfProperty. More... | |
| void | setRenderSelf (bool value) |
| Sets the value of RenderSelfProperty. More... | |
| float | getRenderTargetMinimumHeight () const |
| Gets the value of RenderTargetMinimumHeightProperty. More... | |
| void | setRenderTargetMinimumHeight (float value) |
| Sets the value of RenderTargetMinimumHeightProperty. More... | |
| float | getRenderTargetMinimumWidth () const |
| Gets the value of RenderTargetMinimumWidthProperty. More... | |
| void | setRenderTargetMinimumWidth (float value) |
| Sets the value of RenderTargetMinimumWidthProperty. More... | |
| float | getRenderTargetReallocationLimit () const |
| Gets the value of RenderTargetReallocationLimitProperty. More... | |
| void | setRenderTargetReallocationLimit (float value) |
| Sets the value of RenderTargetReallocationLimitProperty. More... | |
| Vector2 | getRenderTransformationOrigin () const |
| Gets the value of RenderTransformationOriginProperty. More... | |
| void | setRenderTransformationOrigin (Vector2 value) |
| Sets the value of RenderTransformationOriginProperty. More... | |
| bool | isSnapToPixel () const |
| Gets the value of SnapToPixelProperty. More... | |
| void | setSnapToPixel (bool value) |
| Sets the value of SnapToPixelProperty. More... | |
| Public Member Functions inherited from kanzi::Node | |
| virtual | ~Node () |
| Destructor. More... | |
| template<typename DataType > | |
| PropertyType< DataType >::Traits::ReturnType | getProperty (const PropertyType< DataType > &propertyType) const |
| Returns the current value of a property. More... | |
| AbstractPropertyTypeDescriptor::ValueSource * | getNodeFinalValueSource (AbstractPropertyTypeDescriptor &descriptor) const |
| template<typename DataType > | |
| optional< typename PropertyType< DataType >::Traits::ReturnType > | getOptionalProperty (const PropertyType< DataType > &propertyType) const |
| Evaluates the property value in the same way as the overload above but does not default to the value in property metadata if there are no inputs to the property value. More... | |
| template<typename DataType > | |
| DataType | getAbstractProperty (AbstractPropertyType abstractPropertyType) const |
| template<typename DataType > | |
| optional< typename PropertyType< DataType >::DataType > | getOptionalAbstractProperty (AbstractPropertyType abstractPropertyType) const |
| template<typename TMessageType , typename TClass , typename TClassMethod > | |
| MessageSubscriptionToken | addMessageHandler (TMessageType &messageType, TClass *messageHandlerObject, TClassMethod method) |
| Adds a message handler where handler is a method to invoke on an object. More... | |
| template<typename TMessageType , typename TClass , typename TClassMethod > | |
| MessageSubscriptionToken | addMessageFilter (TMessageType &messageType, TClass *messageHandlerObject, TClassMethod method) |
| Adds a message filter where filter is a method to invoke on an object. More... | |
| template<typename TMessageType > | |
| MessageSubscriptionToken | addMessageHandler (const TMessageType &messageType, typename TMessageType::FunctionType function) |
| Adds a message handler where handler is function. More... | |
| template<typename TMessageType > | |
| MessageSubscriptionToken | addMessageFilter (const TMessageType &messageType, typename TMessageType::FunctionType function) |
| Adds a message filter where filter is function. More... | |
| template<typename TMessageType > | |
| MessageSubscriptionToken | addMessageHandler (const TMessageType &messageType, typename TMessageType::FunctionType function, Node *messageSourceFilter) |
| Adds a message handler where handler is function and accepted source is explicitly defined. More... | |
| void | removeMessageHandler (MessageSubscriptionToken token) |
| Removes a message subscription. More... | |
| template<typename TArgumentsType > | |
| void | dispatchMessage (const MessageType< TArgumentsType > &messageType, typename MessageType< TArgumentsType >::ArgumentsType &messageArguments) |
| Dispatches a message with specified arguments. More... | |
| void | addResource (const ResourceID &resourceId, string_view resourceUrl) |
| Adds a resource manager resource to an object node. If resourceID already exists in object, removes the existing entry. If resourceURL is NULL, error is thrown. */. More... | |
| void | removeResource (const ResourceID &resourceId) |
| Removes a resource with given ID from object node resource dictionary. Does not do anything if resourceID was not found. */. More... | |
| bool | containsResource (const ResourceID &resourceID) const |
| Returns if object node resource dictionary contains the resource with given ID. Resource can be any type: style, alias or resource manager resource. */. More... | |
| optional< string > | findResourceURL (const ResourceID &resourceId) const |
| Tries to find Resource URL for Resource ID from this node. More... | |
| ResourceSharedPtr | acquireResource (const ResourceID &id) const |
| Acquires a resource from the node or the node's closest ancestor having the resource id in the resource dictionary. More... | |
| template<typename T > | |
| shared_ptr< T > | acquireResource (const ResourceID &id) const |
| Acquires a resource from the node or the node's closest ancestor having the resource id in the resource dictionary, and casts the resource to given type. More... | |
| ResourceSharedPtr | tryAcquireResource (const ResourceID &id) const |
| Acquires a resource from the node or the node's closest ancestor having the resource id in the resource dictionary. More... | |
| ResourceManager::AcquireTaskSharedPtr | acquireResourceAsync (const ResourceID &key, ResourceManager::AsyncAcquireFinishedCallback func) const |
| Posts an asynchronous task to acquire a resource. More... | |
| template<typename T > | |
| shared_ptr< T > | tryAcquireResource (const ResourceID &id) const |
| Acquires a resource from the node or the node's closest ancestor having the resource and casts the resource to given type. More... | |
| ResourceDictionarySharedPtr | getResourceDictionary () const |
| Gets the resource dictionary of the node, if the node has one. More... | |
| ResourceDictionarySharedPtr | acquireResourceDictionary () |
| Gets the resource dictionary of the node. More... | |
| void | notifyResourceDictionaryModified () |
| Forces the re-evaluation of resource IDs in a node tree. More... | |
| void | setResourceDictionary (ResourceDictionarySharedPtr resourceDictionary) |
| Replaces the resource dictionary of the node. More... | |
| void | addResourceDictionary (ResourceDictionarySharedPtr resourceDictionary) |
| Add a nested resource dictionary to the resource dictionary of the node. More... | |
| void | addAnonymousResource (ResourceSharedPtr resource) |
| Adds alias resource to an object node. More... | |
| void | removeAnonymousResource (const Resource &resource) |
| Removes anonymous resource from object node resources. More... | |
| bool | isNamed (string_view name) const |
| Node * | getParent () const |
| Returns the parent of the node. More... | |
| void | setParent (Node *parent) |
| VisitorResult | visit (const Visitor &visitor, VisitorOrder order) |
| VisitorResult | visitDescendants (const Visitor &visitor, VisitorOrder order) |
| template<typename Type > | |
| shared_ptr< Type > | lookupNode (string_view pathOrKey) |
| Returns a node of specified type by looking it up with specified path or alias. More... | |
| Node * | lookupNodeRaw (string_view relativePath) |
| Get an object node by another node and a relative path. More... | |
| ObjectSharedPtr | lookupObject (string_view relativePath) |
| Lookup for an object from a node. More... | |
| tuple< NodeSharedPtr, AbstractPropertyType > | lookupObjectForStateManager (string_view relativePath) |
| Lookup for an node and possible object from within the node for state manager. More... | |
| template<typename Type > | |
| shared_ptr< Type > | lookupObject (string_view path) |
| Lookup for an object from a node. More... | |
| template<typename TNodeType > | |
| shared_ptr< TNodeType > | findAbstractChild (string_view name) |
| Find a child by name. Finds direct children as well as children connected indirectly for example Viewport->Scene. More... | |
| void | addInputManipulator (InputManipulatorSharedPtr inputManipulator) |
| Transfers the ownership and attaches an input manipulator to an object node. More... | |
| void | removeInputManipulator (InputManipulator &inputManipulator) |
| Removes the ownership and detaches an input manipulator from an object node. More... | |
| InputManipulatorConstIterator | beginInputManipulators () const |
| InputManipulatorConstIterator | endInputManipulators () const |
| void | addBinding (BindingSharedPtr binding) |
| Transfers the ownership of a binding rule to an object node. More... | |
| void | addBindingWithOwner (BindingSharedPtr binding, shared_ptr< void > owner) |
| Transfers the ownership of a binding rule to an object node and sets the owner of binding rule. More... | |
| void | removeBinding (Binding &binding) |
| Removes the ownership and detaches a binding rule from an object node. More... | |
| void | removeBindingsWithOwner (shared_ptr< void > owner) |
| Removes all bindings with the specified owner. More... | |
| BindingConstIterator | beginBindings () const |
| BindingConstIterator | endBindings () const |
| void | addNodeComponent (NodeComponentSharedPtr nodeComponent) |
| Transfers the ownership of a node component to an object node. More... | |
| void | addNodeComponentWithOwner (NodeComponentSharedPtr nodeComponent, const void *owner) |
| Transfers the ownership of a node component to an object node and sets the owner of the node component. More... | |
| void | removeNodeComponent (NodeComponent &nodeComponent) |
| Removes the ownership of a node component from an object node. More... | |
| void | removeNodeComponentWithOwner (const void *owner) |
| Removes all bindings with the specified owner. More... | |
| NodeComponentConstIterator | beginNodeComponents () const |
| NodeComponentConstIterator | endNodeComponents () const |
| template<typename Type > | |
| shared_ptr< Type > | lookupNodeComponent (string_view name) |
| Returns a node component of specified type by looking it up with specified name. More... | |
| void | setRenderable (bool state) |
| Sets whether the object node is renderable. More... | |
| bool | isRenderable () const |
| Returns whether node is renderable. More... | |
| bool | isEffectivelyVisible () const |
| Checks if the node and all of its ancestors are visible. More... | |
| bool | isEffectivelyEnabled () const |
| Checks if the node and all of its ancestors are enabled. More... | |
| uint32_t | getChangeFlags () const |
| Get current change flags. More... | |
| uint32_t | getChildChangeFlags () const |
| Get current child change flags. More... | |
| void | setChangeFlag (uint32_t flag) |
| Sets a change flag. More... | |
| void | clearChangeFlag (uint32_t flag) |
| Clears a change flag. More... | |
| bool | isChangeFlagSet (uint32_t flag) const |
| Checks if a change flag is set. More... | |
| bool | isAnyChangeFlagSet (uint32_t flag) const |
| Checks if any of given flags is set. More... | |
| void | setChildChangeFlag (uint32_t flag) |
| Sets a child change flag. More... | |
| void | clearChildChangeFlag (uint32_t flag) |
| Clears a child change flag. More... | |
| bool | isChildChangeFlagSet (uint32_t flag) const |
| Checks if child change flags match. More... | |
| bool | isAnyChildChangeFlagSet (uint32_t flag) const |
| Checks if any child change flags (corresponding to given mask) are set. More... | |
| bool | isInvalidMeasure () const |
| Check if the node needs measure. More... | |
| void | invalidateMeasure () |
| Invalidates measure for the node. More... | |
| void | validateMeasure () |
| Validates measure for the node. More... | |
| bool | isInvalidArrange () const |
| Checks if the node needs arrange. More... | |
| void | invalidateArrange () |
| Invalidates arrange. More... | |
| void | validateArrange () |
| Validates arrange. More... | |
| bool | isInvalidRender () const |
| Returns if node render flag is invalid. More... | |
| void | validateRender () |
| Validates render for node. More... | |
| void | invalidateRender () |
| Invalidates render for node. More... | |
| bool | isInvalidFinalTransform () const |
| Tells if final transform flag is invalid for node. More... | |
| void | invalidateFinalTransform () |
| Invalidates final transform for node. More... | |
| bool | isInvalidDraw () |
| Tells if node draw flag is invalid. More... | |
| void | invalidateDraw () |
| Invalidates draw flag for the node. More... | |
| void | validateDraw () |
| Validates draw flags for the node. More... | |
| void | validateDrawForChildrenRecursive () |
| Recursively validates draw for the children from this 2D node onwards. More... | |
| bool | isInitialized () const |
| Returns true if initialize() has been called, false otherwise. More... | |
| bool | isAttached () const |
| Returns true if the node is attached to a screen or one of its descendants. More... | |
| bool | isAttaching () const |
| Returns true if node is in the process of attaching, false otherwise. More... | |
| bool | isDetaching () const |
| Returns true if the node currently detaching. More... | |
| void | attachRecursive () |
| Attaches an object node and its children recursively. More... | |
| void | detachRecursive () |
| Detaches an object node and its children recursively. More... | |
| virtual const KzuBoundingVolume * | getBoundingVolume () const |
| Gets bounding volume from object node. More... | |
| AppliedStyleEntrySharedPtr | applyStyle (StyleSharedPtr style) |
| Applies a style to an object node. More... | |
| AppliedStyleEntrySharedPtr | applyManualStyle (StyleSharedPtr style) |
| Applies a style to an object node. More... | |
| void | unapplyStyle (AppliedStyleEntrySharedPtr appliedStyleEntry) |
| Unapplies a style from an object node. More... | |
| void | applyStyles () |
| Apply all styles for an object node. More... | |
| void | unapplyStyles () |
| Unapplies and removes all applied styles. More... | |
| void | applyStylesRecursive () |
| Applies styles recursively. More... | |
| void | unapplyStylesRecursive () |
| Unapplies styles recursively. More... | |
| void | removeKZBData () |
| Destroys all object node data loaded from KZB, including properties, bindings, node comopnents, resources etc. More... | |
| void | addResourceReference (AbstractPropertyType propertyType, AbstractResourceReference *reference) |
| This is a helper for automatic resource tracking in ResourceReference. More... | |
| void | removeResourceReference (const AbstractResourceReference &reference) |
| This is a helper for automatic resource tracking in ResourceReference. More... | |
| void | addNodeReference (AbstractPropertyType propertyType, AbstractNodeReference *reference) |
| void | removeNodeReference (const AbstractNodeReference &reference) |
| ScriptingContextSharedPtr | getScriptingContext () const |
| void | setScriptingContext (ScriptingContextSharedPtr context) |
| void | setTemplateRoot (NodeSharedPtr templateRoot) |
| Sets the template root of this node. More... | |
| NodeSharedPtr | getTemplateRoot () const |
| Gets the template root of this node. More... | |
| bool | trySetActiveFocus () |
| The method tries to move the active focus on this node. More... | |
| string | getName () const |
| Gets the value of NameProperty. More... | |
| void | setName (string_view value) |
| Sets the value of NameProperty. More... | |
| string | getPath () const |
| Gets the value of PathProperty. More... | |
| void | setPath (string value) |
| Sets the value of PathProperty. More... | |
| string | getLocale () const |
| Gets the value of LocaleProperty. More... | |
| void | setLocale (string value) |
| Sets the value of LocaleProperty. More... | |
| bool | isHitTestable () const |
| Gets the value of HitTestableProperty. More... | |
| void | setHitTestable (bool value) |
| Sets the value of HitTestableProperty. More... | |
| bool | isHitTestableContainer () const |
| Gets the value of HitTestableContainerProperty. More... | |
| void | setHitTestableContainer (bool value) |
| Sets the value of HitTestableContainerProperty. More... | |
| bool | isVisible () const |
| Gets the value of VisibleProperty. More... | |
| void | setVisible (bool value) |
| Sets the value of VisibleProperty. More... | |
| bool | isEnabled () const |
| Gets the value of EnabledProperty. More... | |
| void | setEnabled (bool value) |
| Sets the value of EnabledProperty. More... | |
| bool | isFocusable () const |
| Gets the value of FocusableProperty. More... | |
| void | setFocusable (bool value) |
| Sets the value of FocusableProperty. More... | |
| bool | isFocused () const |
| Gets the value of FocusedProperty. More... | |
| void | setFocused (bool value) |
| Sets the value of FocusedProperty. More... | |
| bool | hasLogicalFocus () const |
| Returns the #LogicalFocusedProperty value. More... | |
| void | setLogicalFocus (bool value) |
| Sets the value of LogicalFocusProperty. More... | |
| FontSharedPtr | getFont () const |
| Gets the value of FontProperty. More... | |
| void | setFont (FontSharedPtr value) |
| Sets the value of FontProperty. More... | |
| float | getVisibleAmountInParent () const |
| Gets the value of VisibleAmountInParentProperty. More... | |
| void | setVisibleAmountInParent (float value) |
| Sets the value of VisibleAmountInParentProperty. More... | |
| float | getProjection2DTo3DScale () const |
| Gets the value of Projection2DTo3DScaleProperty. More... | |
| void | setProjection2DTo3DScale (float value) |
| Sets the value of Projection2DTo3DScaleProperty. More... | |
| bool | isEnableClick () const |
| Gets the value of EnableClickProperty. More... | |
| void | setEnableClick (bool value) |
| Sets the value of EnableClickProperty. More... | |
| bool | isEnableMultiClick () const |
| Gets the value of EnableMultiClickProperty. More... | |
| void | setEnableMultiClick (bool value) |
| Sets the value of EnableMultiClickProperty. More... | |
| ResourceSharedPtr | getStyle () const |
| Gets the value of StyleProperty. More... | |
| void | setStyle (ResourceSharedPtr value) |
| Sets the value of StyleProperty. More... | |
| ResourceSharedPtr | getStateManager () const |
| Gets the value of StateManagerProperty. More... | |
| void | setStateManager (ResourceSharedPtr value) |
| Sets the value of StateManagerProperty. More... | |
| float | getWidth () const |
| Gets the value of WidthProperty. More... | |
| void | setWidth (float value) |
| Sets the value of WidthProperty. More... | |
| float | getHeight () const |
| Gets the value of HeightProperty. More... | |
| void | setHeight (float value) |
| Sets the value of HeightProperty. More... | |
| float | getDepth () const |
| Gets the value of DepthProperty. More... | |
| void | setDepth (float value) |
| Sets the value of DepthProperty. More... | |
| float | getActualWidth () const |
| Gets the value of ActualWidthProperty. More... | |
| void | setActualWidth (float value) |
| Sets the value of ActualWidthProperty. More... | |
| float | getActualHeight () const |
| Gets the value of ActualHeightProperty. More... | |
| void | setActualHeight (float value) |
| Sets the value of ActualHeightProperty. More... | |
| float | getActualDepth () const |
| Gets the value of ActualDepthProperty. More... | |
| void | setActualDepth (float value) |
| Sets the value of ActualDepthProperty. More... | |
| Node::HorizontalAlignment | getHorizontalAlignment () const |
| Gets the value of HorizontalAlignmentProperty. More... | |
| void | setHorizontalAlignment (Node::HorizontalAlignment value) |
| Sets the value of HorizontalAlignmentProperty. More... | |
| Node::VerticalAlignment | getVerticalAlignment () const |
| Gets the value of VerticalAlignmentProperty. More... | |
| void | setVerticalAlignment (Node::VerticalAlignment value) |
| Sets the value of VerticalAlignmentProperty. More... | |
| Node::DepthAlignment | getDepthAlignment () const |
| Gets the value of DepthAlignmentProperty. More... | |
| void | setDepthAlignment (Node::DepthAlignment value) |
| Sets the value of DepthAlignmentProperty. More... | |
| Vector2 | getHorizontalMargin () const |
| Gets the value of HorizontalMarginProperty. More... | |
| void | setHorizontalMargin (Vector2 value) |
| Sets the value of HorizontalMarginProperty. More... | |
| Vector2 | getVerticalMargin () const |
| Gets the value of VerticalMarginProperty. More... | |
| void | setVerticalMargin (Vector2 value) |
| Sets the value of VerticalMarginProperty. More... | |
| Vector2 | getDepthMargin () const |
| Gets the value of DepthMarginProperty. More... | |
| void | setDepthMargin (Vector2 value) |
| Sets the value of DepthMarginProperty. More... | |
| Node::ContentStretch | getContentStretch () const |
| Gets the value of ContentStretchProperty. More... | |
| void | setContentStretch (Node::ContentStretch value) |
| Sets the value of ContentStretchProperty. More... | |
| float | getOpacity () const |
| Gets the value of OpacityProperty. More... | |
| void | setOpacity (float value) |
| Sets the value of OpacityProperty. More... | |
| bool | isHover () const |
| Returns whether the node has HoverProperty set to true. More... | |
| bool | isClipChildren () const |
| Gets the value of ClipChildrenProperty. More... | |
| void | setClipChildren (bool value) |
| Sets the value of ClipChildrenProperty. More... | |
| Public Member Functions inherited from kanzi::Object | |
| Object (Domain *domain) | |
| virtual | ~Object () |
| Domain * | getDomain () const |
| Returns the domain the object belongs to. More... | |
| KzuTaskScheduler * | getTaskScheduler () const |
| Returns the task scheduler of the object. More... | |
| KzuMessageDispatcher * | getMessageDispatcher () const |
| Returns the message dispatcher of the object. More... | |
| ResourceManager * | getResourceManager () const |
| Returns the resource manager of the object. More... | |
| virtual const Metaclass * | getDynamicMetaclass () const KZ_OVERRIDE |
| Returns the metaclass of the dynamic type of the object. More... | |
| AppliedStyleEntrySharedPtr | applyObjectStyle (kanzi::StyleSharedPtr style) |
| Applies a style to an object. More... | |
| void | unapplyObjectStyle (AppliedStyleEntrySharedPtr appliedStyleEntry) |
| void | applyObjectStyles () |
| Apply all styles for an object node. More... | |
| void | unapplyObjectStyles () |
| Unapplies and removes all applied styles. More... | |
| Public Member Functions inherited from kanzi::MetaObject | |
| virtual | ~MetaObject () |
| bool | isTypeOf (const Metaclass *objectType) const |
| Determines if the type of this object is the given type or derived from it. More... | |
| Public Member Functions inherited from kanzi::PropertyObject | |
| PropertyObject () | |
| virtual | ~PropertyObject () |
| template<typename DataType > | |
| void | setProperty (const PropertyType< DataType > &propertyType, typename PropertyType< DataType >::Traits::ParameterType value) |
| Sets the local value of a property. More... | |
| void | removeKzbProperties () |
| template<typename DataType > | |
| PropertyType< DataType >::Traits::ReturnType | getProperty (const PropertyType< DataType > &propertyType) const |
| Returns the current value of a property. More... | |
| template<typename DataType > | |
| optional< typename PropertyType< DataType >::Traits::ReturnType > | getOptionalProperty (const PropertyType< DataType > &propertyType) const |
| Evaluates the property value in the same way as the overload above but does not default to the value in property metadata if there are no inputs to the property value. More... | |
| template<typename DataType > | |
| PropertyType< DataType >::Traits::ReturnType | getPropertyBase (const PropertyType< DataType > &propertyType) const |
| Returns the current value of a property disregarding modifiers. More... | |
| template<typename DataType > | |
| void | setAbstractProperty (AbstractPropertyType abstractPropertyType, typename PropertyType< DataType >::Traits::ParameterType value) |
| template<typename DataType > | |
| PropertyType< DataType >::Traits::ReturnType | getAbstractProperty (AbstractPropertyType abstractPropertyType) const |
| template<typename DataType > | |
| PropertyType< DataType >::Traits::ReturnType | getAbstractPropertyBase (AbstractPropertyType abstractPropertyType) const |
| template<typename DataType > | |
| optional< typename PropertyType< DataType >::Traits::ReturnType > | getOptionalAbstractProperty (AbstractPropertyType abstractPropertyType) const |
| void | setPropertyFlag (AbstractPropertyType propertyType, uint32_t flag) |
| bool | isPropertyFlagSet (AbstractPropertyType propertyType, uint32_t flag) const |
| void | clearPropertyFlag (AbstractPropertyType propertyType, uint32_t flag) |
| bool | hasValue (AbstractPropertyType propertyType) const |
| Evaluates whether there are any inputs into the property value. More... | |
| bool | hasBaseValue (AbstractPropertyType propertyType) const |
| Evaluates whether there are any inputs into the property value, disregarding modifiers. More... | |
| bool | hasLocalValue (AbstractPropertyType propertyType) const |
| Evaluates whether there is a local value set for the property. More... | |
| bool | hasNonClassValue (AbstractPropertyType propertyType) const |
| Evaluates whether there is a value of any precedence higher than class default value set for the property. More... | |
| void | removeLocalValue (AbstractPropertyType propertyType) |
| Removes the local value associated with the property. More... | |
| void | copyLocalValue (const PropertyObject &other, AbstractPropertyType propertyType) |
| Copies local value of single property from another object. More... | |
| void | copyLocalValues (const PropertyObject &other) |
| Copies all local values from another object. More... | |
| template<typename DataType > | |
| void | addPropertyValueSource (const PropertyType< DataType > &propertyType, typename PropertyType< DataType >::Descriptor::TypedValueSource *valueSource, PropertyValuePrecedence precedence, void *owner) |
| template<typename DataType > | |
| void | removePropertyValueSource (const PropertyType< DataType > &propertyType, typename PropertyType< DataType >::Descriptor::TypedValueSource *valueSource, void *owner) |
| template<typename DataType > | |
| void | addPropertyModifier (const PropertyType< DataType > &propertyType, typename PropertyType< DataType >::Descriptor::ModifierCallback callback, void *owner) |
| template<typename DataType > | |
| void | removePropertyModifier (const PropertyType< DataType > &propertyType, typename PropertyType< DataType >::Descriptor::ModifierCallback callback, void *owner) |
| void | validatePropertyModifiers (AbstractPropertyType propertyType) |
| template<typename DataType > | |
| void | addPropertyNotificationHandler (const PropertyType< DataType > &propertyType, typename PropertyType< DataType >::Descriptor::NotificationCallback callback, void *owner) |
| template<typename DataType > | |
| void | removePropertyNotificationHandler (const PropertyType< DataType > &propertyType, typename PropertyType< DataType >::Descriptor::NotificationCallback callback, void *owner) |
| template<typename DataType > | |
| size_t | getPropertyNotificationHandlerCount (const PropertyType< DataType > &propertyType) |
| Gets number of current notification handlers for given property type. More... | |
Static Public Member Functions | |
| static TextBlock2DSharedPtr | create (Domain *domain, string_view name) |
| Creates a TextBlock2D node. More... | |
| static TextBlock2DSharedPtr | create (Domain *domain, string_view name, string_view text) |
| Static Public Member Functions inherited from kanzi::TextBlockConceptImpl< Node2D, TextBlock2D > | |
| static PropertyTypeEditorInfoSharedPtr | makeEditorInfo () |
| Static Public Member Functions inherited from kanzi::Node2D | |
| static float | layoutUp () |
| static bool | isValidLayoutSize (Vector2 size) |
| Indicates whether a size is valid layout size. More... | |
| static Vector2 | unboundedLayoutSize () |
| Returns an unbounded layout size. More... | |
| static bool | isUnboundedLayoutSize (Vector2 layoutSize) |
| Indicates whether a layout size is an unbound layout size. More... | |
| static Vector2 | replaceUnboundedLayoutSize (Vector2 layoutSize, Vector2 resetSize) |
| Replaces any element of a layout size with appropriate element of the reset size if it is unbounded and returns the size. More... | |
| static Vector2 | replaceUnboundedLayoutSizeWithZero (Vector2 layoutSize) |
| Replaces any element of a layout size with zero if it is unbounded and returns the size. More... | |
| static PropertyTypeEditorInfoSharedPtr | makeEditorInfo () |
| Static Public Member Functions inherited from kanzi::Node | |
| static bool | isValidLayoutValue (float value) |
| Indicates whether a value is valid layout value. More... | |
| static float | unboundedLayoutValue () |
| Returns an unbounded layout value. More... | |
| static bool | isUnboundedLayoutValue (float layoutValue) |
| Indicates whether a value is an unbound layout value. More... | |
| static float | replaceUnboundedLayoutValue (float layoutValue, float resetValue) |
| Replaces layout value with the specified value if it is unbounded and returns it. More... | |
| static float | replaceUnboundedLayoutValueWithZero (float layoutValue) |
| Replaces layout value with zero if it is unbounded layout value and returns it. More... | |
| Static Public Member Functions inherited from kanzi::Object | |
| static const Metaclass * | getStaticMetaclass () |
| Returns the metaclass of Object class. More... | |
| static PropertyTypeEditorInfoSharedPtr | makeEditorInfo () |
| Default implementation that returns empty editor info. More... | |
| Static Public Member Functions inherited from kanzi::MetaObject | |
| static const Metaclass * | getStaticMetaclass () |
| Returns the metaclass of Object class. More... | |
| static PropertyTypeEditorInfoSharedPtr | makeEditorInfo () |
| Default implementation that returns empty editor info. More... | |
| Static Public Member Functions inherited from kanzi::TextBlockConcept | |
| static PropertyTypeEditorInfoSharedPtr | makeEditorInfo () |
Protected Member Functions | |
| TextBlock2D (Domain *domain, string_view name) | |
| Constructor. More... | |
| virtual Vector2 | measureOverride (Vector2 availableSize) KZ_OVERRIDE |
| Node2D::measure() implementation. More... | |
| virtual void | arrangeOverride (Vector2 actualSize) KZ_OVERRIDE |
| Node2D::arrange() implementation. More... | |
| virtual void | updateRenderOverride () KZ_OVERRIDE |
| Node2D::updateRenderOverride() implementation. More... | |
| virtual void | onAttached () KZ_OVERRIDE |
| Node2D::onAttached() implementation. More... | |
| virtual void | onDetached () KZ_OVERRIDE |
| Node2D::onDetached() implementation. More... | |
| virtual void | renderSelfOverride (Renderer3D &renderer, CompositionStack &compositionStack, const Matrix3x3 &baseTransform) KZ_OVERRIDE |
| Node2D::renderSelfOverride() implementation. More... | |
| virtual void | onNodePropertyChanged (AbstractPropertyType propertyType, PropertyNotificationReason reason) KZ_OVERRIDE |
| Node2D::onNodePropertyChanged() implementation. More... | |
| void | arrangeText () |
| Positions the text and prepares the rendering data. More... | |
| Vector2 | calculateAlignmentOffset () const |
| Returns how much the text format needs to be translated so that it is positioned according to the alignment properties. More... | |
| Protected Member Functions inherited from kanzi::TextBlockConceptImpl< Node2D, TextBlock2D > | |
| TextBlockConceptImpl (Domain *domain, string_view name) | |
| Constructor. More... | |
| void | prepareTextFormat (float textFormatWidth, float textFormatHeight, bool constrainToActualSize) |
| Position the text. More... | |
| void | prepareTextFormat (float textFormatWidth, float textFormatHeight, bool measure, bool ceiledSizes) |
| Position the text. More... | |
| virtual void | onPostPrepareTextFormatMeasure (bool completeRelayoutingExecuted) |
| When in measure layouting phase, Kanzi calls this function every time it completes the prepareTextFormat function. More... | |
| virtual void | onPostPrepareTextFormatArrange (bool completeRelayoutingExecuted) |
| When in arrange layouting phase, Kanzi calls this function every time it completes the prepareTextFormat function. More... | |
| Protected Member Functions inherited from kanzi::Node2D | |
| Node2D (Domain *domain, string_view name) | |
| Constructor. More... | |
| void | initialize () |
| NodeVisual2D & | acquireVisual () |
| Initializes and returns visual structure. More... | |
| virtual void | renderOverride (Renderer3D &renderer, CompositionStack &compositionStack) |
| Node-specific top-level render call. More... | |
| void | renderRecursive (Renderer3D &renderer, CompositionStack &compositionStack, const Matrix3x3 &baseTransform) |
| Render a Node2D and then recursively all its children. More... | |
| void | renderChildren (Renderer3D &renderer, CompositionStack &compositionStack, const Matrix3x3 &baseTransform) |
| Render all children of a Node2D. More... | |
| void | renderBackground (Renderer3D &renderer, const CompositionStack &compositionStack, const Matrix3x3 &baseTransform) |
| Render background quad of a Node2D. More... | |
| void | renderForeground (Renderer3D &renderer, CompositionStack &compositionStack, const Matrix3x3 &baseTransform) |
| Render foreground of a Node2D. More... | |
| virtual void | renderForegroundOverride (Renderer3D &renderer, CompositionStack &compositionStack, const Matrix3x3 &baseTransform) |
| Node-specific foreground render. More... | |
| bool | pushLocalViewportArea (CompositionStack &compositionStack) |
| Push local viewport and scissor area into composition stack if it's required. More... | |
| NodeCompositor2D & | acquireCompositor () |
| Initializes and returns composition structure. More... | |
| void | clearCompositionTarget (Renderer3D &renderer, CompositionStack &compositionStack, bool clearColor) |
| Clear node render target. More... | |
| virtual void | arrangeRecursive (const Matrix3x3 &worldTransform, const Matrix3x3 &parentTransform, bool arrangeNeeded, bool transformChanged) |
| Perform arrange recursively. More... | |
| optional< float > | getUserAspectRatio () const |
| Get aspect ratio property assigned to the node. More... | |
| optional< float > | getUserHeight () const |
| Get layout height property assigned to the node. More... | |
| optional< float > | getUserWidth () const |
| Get layout width property assigned to the node. More... | |
| Vector2 | getDesiredSizeAxisAlignedBoundingBoxMinimum () const |
| Get desired size axis aligned bounding box minimum. More... | |
| void | setDesiredSizeAxisAlignedBoundingBoxMinimum (Vector2 size) |
| Set desired size axis aligned bounding box minimum. More... | |
| void | setDesiredSizeAxisAlignedBoundingBoxMinimum (float sizeX, float sizeY) |
| Set desired size axis aligned bounding box minimum. More... | |
| Vector2 | getDesiredSizeAxisAlignedBoundingBoxMaximum () const |
| Get desired size axis aligned bounding box maximum. More... | |
| void | setDesiredSizeAxisAlignedBoundingBoxMaximum (Vector2 size) |
| Set desired size axis aligned bounding box maximum. More... | |
| void | setDesiredSizeAxisAlignedBoundingBoxMaximum (float sizeX, float sizeY) |
| Set desired size maximum. More... | |
| void | calculateTransformedBoundingArea (const Matrix3x3 &transform, Vector2 sizeIn) |
| Calculate new transformed bounding area. More... | |
| Matrix3x3 | updateFinalTransform (const Matrix3x3 &worldTransform, const Matrix3x3 &parentTransform) |
| Update final transformation. More... | |
| bool | updateRender (const Matrix3x3 &worldTransform, const Matrix3x3 &parentTransform, bool transformChanged) |
| Validate node for rendering. More... | |
| optional< QuadDescription > | calculateContentStretch (Vector2 renderSize, Vector2 contentSize) |
| Calculate content stretch. More... | |
| ClippingArea | calculateClippingArea (const Matrix3x3 &parentSpaceTransform) const |
| Calculate clipping parameters. More... | |
| unsigned int | performClipping (QuadDescription &backgroundQuad, optional< QuadDescription > &foregroundQuad, unsigned int clippingResult) |
| Perform rectangle clipping. More... | |
| void | extractChildren () const |
| Extract children of node, called from extraction implementations. More... | |
| virtual void | onExtract () |
| Node2D extract function. More... | |
| virtual void | restoreResources () KZ_OVERRIDE |
| Node::restoreResources() implementation. More... | |
| bool | isEmptyActualSize () const |
| Tell if the size of the node is empty or invalid. More... | |
| bool | isForegroundHintOpaque () const |
| Tell if foreground hint is opaque. More... | |
| bool | isForegroundHintTranslucent () const |
| Tell if foreground hint is translucent. More... | |
| bool | isForegroundTranslucencyRequested () const |
| Tell if foreground translucency has been requested. More... | |
| void | setForegroundTranslucencyRequested (bool enabled) |
| Turn foreground translucency request on or off. More... | |
| void | setPartialArrangeTransform (Matrix3x3 transform) |
| Sets partial arrange transform. More... | |
| void | setRenderChildrenAllowed (bool enabled) |
| Turn render children on or off. More... | |
| void | setRenderSelfAllowed (bool enabled) |
| Turn render self on or off. More... | |
| void | setRenderType (RenderType renderType) |
| Set render type. More... | |
| void | updateContentTexture (TextureSharedPtr texture) |
| Update content texture for the foreground brush. More... | |
| void | setSecondPassDesiredSize (Vector2 size) |
| Set second pass desired size. More... | |
| Protected Member Functions inherited from kanzi::Node | |
| Node (Domain *domain, string_view name) | |
| Constructor. More... | |
| void | initialize () |
| void | updatePropertiesForConnectedNode () |
| Invokes property notifications for inherited properties during scene graph tree connections. More... | |
| void | updatePropertiesForDisconnectedNode (Node *oldParent) |
| Invokes property notifications for inherited properties during scene graph tree disconnections. More... | |
| void | updateResourceReferences () |
| void | updateResourceReferences (AbstractPropertyType propertyType) |
| void | updateResourceReferencesRecursive () |
| void | updateResourceReferencesRecursive (const ResourceID &resourceID) |
| void | attach () |
| Attaches the object node. More... | |
| void | detach () |
| Detaches the object node. More... | |
| virtual void | notifyPropertyHandlers (PropertyStoragePtr &propertyStorage, PropertyNotificationReason reason) KZ_OVERRIDE |
| Protected Member Functions inherited from kanzi::Object | |
| void | initialize () |
| void | onCopy (const Object &other) |
| Protected Member Functions inherited from kanzi::MetaObject | |
| MetaObject () | |
| void | initialize () |
| Protected Member Functions inherited from kanzi::PropertyObject | |
| void | addPropertyValueSource (AbstractPropertyTypeDescriptor &descriptor, AbstractPropertyTypeDescriptor::ValueSource *valueSource, PropertyValuePrecedence precedence, void *owner) |
| void | removePropertyValueSource (AbstractPropertyTypeDescriptor &descriptor, AbstractPropertyTypeDescriptor::ValueSource *valueSource, void *owner) |
| AbstractPropertyTypeDescriptor::ValueSourceEntry * | getTopValueSourceEntry (AbstractPropertyTypeDescriptor::PropertyStorage &propertyStorage) const |
| AbstractPropertyTypeDescriptor::ValueSourceEntry * | getTopValueSourceEntry (AbstractPropertyTypeDescriptor &descriptor) const |
| AbstractPropertyTypeDescriptor::ValueSource * | getTopValueSource (AbstractPropertyTypeDescriptor &descriptor) const |
| AbstractPropertyTypeDescriptor::ValueSource * | getFinalValueSource (AbstractPropertyTypeDescriptor &descriptor) const |
| AbstractPropertyTypeDescriptor::ValueSource * | getNonClassValueSource (AbstractPropertyTypeDescriptor &descriptor) const |
| AbstractPropertyTypeDescriptor::ValueSource * | getClassValueSource (AbstractPropertyTypeDescriptor &descriptor) const |
| AbstractPropertyTypeDescriptor::ValueSourceEntry * | findLocalValueSourceEntry (AbstractPropertyTypeDescriptor::PropertyStorage &propertyStorage) |
| AbstractPropertyTypeDescriptor::ValueSourceEntry * | constructLocalValueSourceEntry (AbstractPropertyTypeDescriptor &descriptor, AbstractPropertyTypeDescriptor::PropertyStorage &propertyStorage) |
| AbstractPropertyTypeDescriptor::ValueSourceEntry * | acquireLocalValueSourceEntry (AbstractPropertyTypeDescriptor &descriptor, PropertyStoragePtr &propertyStorage) |
| AbstractPropertyTypeDescriptor::PropertyStorage * | findPropertyStorage (AbstractPropertyTypeDescriptor &descriptor) const |
| PropertyStoragePtr | findPropertyStoragePtr (AbstractPropertyTypeDescriptor &descriptor) const |
| Gets property storage intrusive pointer that can be used to hold a reference until end of operation. More... | |
| PropertyStoragePtr | constructPropertyStorage (AbstractPropertyTypeDescriptor &descriptor) |
| PropertyStoragePtr | acquirePropertyStorage (AbstractPropertyTypeDescriptor &descriptor) |
| AbstractPropertyTypeDescriptor::ModifierStorage * | acquireModifierStorage (AbstractPropertyTypeDescriptor &descriptor, AbstractPropertyTypeDescriptor::PropertyStorage &propertyStorage) |
| AbstractPropertyTypeDescriptor::ModifierStorage * | findModifierStorage (AbstractPropertyTypeDescriptor &descriptor) |
| AbstractPropertyTypeDescriptor::NotificationStorage * | acquireNotificationStorage (AbstractPropertyTypeDescriptor &descriptor) |
| AbstractPropertyTypeDescriptor::NotificationStorage * | findNotificationStorage (AbstractPropertyTypeDescriptor &descriptor) |
| AbstractPropertyTypeDescriptor * | findPropertyTypeDescriptorByUnqualifiedNameAndDataType (string_view unqualifiedName, PropertyDataType dataType) |
| void | validatePropertyModifiersAndNotifyHandlers (PropertyStoragePtr &propertyStorage) |
| void | copyLocalValue (const AbstractPropertyTypeDescriptor::PropertyStorage &otherPropertyStorage) |
| Copy local value from property storage. More... | |
| PropertyStorageContainer::iterator | beginPropertyStorage () |
| PropertyStorageContainer::iterator | endPropertyStorage () |
| void | onCopy (const PropertyObject &other) |
Additional Inherited Members | |
| Static Public Attributes inherited from kanzi::Node2D | |
| static PropertyType< float > | AspectRatioProperty |
| AspectRatio property. More... | |
| static PropertyType< bool > | ForceCompositionProperty |
| ForceComposition property. More... | |
| static PropertyType< Node2D::ForegroundHint > | ForegroundHintProperty |
| ForegroundHint property. More... | |
| static PropertyType< bool > | CacheChildrenProperty |
| CacheChildren property. More... | |
| static PropertyType< bool > | CacheResultProperty |
| CacheResult property. More... | |
| static PropertyType< bool > | CacheSelfProperty |
| CacheSelf property. More... | |
| static PropertyType< bool > | OffscreenRenderingProperty |
| OffscreenRendering property. More... | |
| static PropertyType< bool > | DisableRenderTargetClearProperty |
| DisableRenderTargetClear property. More... | |
| static PropertyType< Node2D::PixelFormat > | PixelFormatProperty |
| PixelFormat property. More... | |
| static PropertyType< bool > | RenderSelfProperty |
| RenderSelf property. More... | |
| static PropertyType< ResourceSharedPtr > | RenderTargetProperty |
| RenderTarget property. More... | |
| static PropertyType< float > | RenderTargetMinimumHeightProperty |
| RenderTargetMinimumHeight property. More... | |
| static PropertyType< float > | RenderTargetMinimumWidthProperty |
| RenderTargetMinimumWidth property. More... | |
| static PropertyType< float > | RenderTargetReallocationLimitProperty |
| RenderTargetReallocationLimit property. More... | |
| static PropertyType< SRTValue2D > | LayoutTransformationProperty |
| LayoutTransformation property. More... | |
| static PropertyType< SRTValue2D > | RenderTransformationProperty |
| RenderTransformation property. More... | |
| static PropertyType< SRTValue3D > | PerspectiveTransformationProperty |
| PerspectiveTransformation property. More... | |
| static PropertyType< Vector2 > | RenderTransformationOriginProperty |
| RenderTransformationOrigin property. More... | |
| static PropertyType< bool > | SnapToPixelProperty |
| SnapToPixel property. More... | |
| static PropertyType< ResourceSharedPtr > | BackgroundBrushProperty |
| BackgroundBrush property. More... | |
| static PropertyType< ResourceSharedPtr > | CompositionBrushProperty |
| CompositionBrush property. More... | |
| static PropertyType< ResourceSharedPtr > | ForegroundBrushProperty |
| ForegroundBrush property. More... | |
| Static Public Attributes inherited from kanzi::Node | |
| static PropertyType< string > | NameProperty |
| Name property. More... | |
| static PropertyType< string > | PathProperty |
| Path property. More... | |
| static PropertyType< string > | LocaleProperty |
| Locale property. More... | |
| static PropertyType< bool > | CreatedFromKZBProperty |
| CreatedFromKZB property. More... | |
| static PropertyType< bool > | HitTestableProperty |
| HitTestable property. More... | |
| static PropertyType< bool > | HitTestableContainerProperty |
| HitTestableContainer property. More... | |
| static PropertyType< bool > | VisibleProperty |
| Visible property. More... | |
| static PropertyType< bool > | EnabledProperty |
| Enabled property. More... | |
| static PropertyType< bool > | FocusableProperty |
| The property specifies whether a node can get active focus and can participate in the focus chain navigation. More... | |
| static PropertyType< bool > | FocusedProperty |
| Specifies that the node is the active focus node, which receives keyboard messages. More... | |
| static PropertyType< bool > | LogicalFocusProperty |
| Specifies that the node has logical focus state. More... | |
| static PropertyType< ResourceSharedPtr > | FontProperty |
| Font property. More... | |
| static PropertyType< float > | VisibleAmountInParentProperty |
| VisibleAmountInParent property. More... | |
| static PropertyType< float > | Projection2DTo3DScaleProperty |
| Projection2DTo3DScale property. More... | |
| static PropertyType< bool > | EnableClickProperty |
| EnableClick property. More... | |
| static PropertyType< bool > | EnableMultiClickProperty |
| EnableMultiClick property. More... | |
| static PropertyType< ResourceSharedPtr > | StyleProperty |
| Style property. More... | |
| static PropertyType< ResourceSharedPtr > | StateManagerProperty |
| StateManager property. More... | |
| static PropertyType< void * > | PrefabTemplateSourceProperty |
| PrefabTemplateSource property. More... | |
| static PropertyType< float > | WidthProperty |
| Width property. More... | |
| static PropertyType< float > | HeightProperty |
| Height property. More... | |
| static PropertyType< float > | DepthProperty |
| Depth property. More... | |
| static PropertyType< float > | ActualWidthProperty |
| ActualWidth property. More... | |
| static PropertyType< float > | ActualHeightProperty |
| ActualHeight property. More... | |
| static PropertyType< float > | ActualDepthProperty |
| ActualDepth property. More... | |
| static PropertyType< Node::HorizontalAlignment > | HorizontalAlignmentProperty |
| HorizontalAlignment property. More... | |
| static PropertyType< Node::VerticalAlignment > | VerticalAlignmentProperty |
| VerticalAlignment property. More... | |
| static PropertyType< Node::DepthAlignment > | DepthAlignmentProperty |
| DepthAlignment property. More... | |
| static PropertyType< Vector2 > | HorizontalMarginProperty |
| Sets the horizontal space between this node and other nodes that are adjacent to this node in a layout. More... | |
| static PropertyType< Vector2 > | VerticalMarginProperty |
| Sets the vertical space between this node and other nodes that are adjacent to this node in a layout. More... | |
| static PropertyType< Vector2 > | DepthMarginProperty |
| Sets the space in the depth direction between this node and other nodes that are adjacent to this node in a layout. More... | |
| static PropertyType< Node::ContentStretch > | ContentStretchProperty |
| ContentStretch property. More... | |
| static PropertyType< float > | OpacityProperty |
| Opacity property. More... | |
| static PropertyType< bool > | HoverProperty |
| Kanzi updates the HoverProperty for a hit testable node to indicate whether the node is the foremost node under the cursor. More... | |
| static PropertyType< bool > | ClipChildrenProperty |
| ClipChildren property. More... | |
| static PropertyType< int > | SceneGraphAddNodeChangeChildFlagsProperty |
| SceneGraphAddNodeChangeChildFlags property. More... | |
| static PropertyType< int > | SceneGraphAddNodeChangeParentFlagsProperty |
| SceneGraphAddNodeChangeParentFlags property. More... | |
| static PropertyType< int > | SceneGraphRemoveNodeChangeChildFlagsProperty |
| SceneGraphRemoveNodeChangeChildFlags property. More... | |
| static PropertyType< int > | SceneGraphRemoveNodeChangeParentFlagsProperty |
| SceneGraphRemoveNodeChangeParentFlags property. More... | |
| Static Public Attributes inherited from kanzi::TextBlockConcept | |
| static PropertyType< ColorRGBA > | FontColorProperty |
| Use the Font Color property to set the text color for the default font material and for the materials with a fragment shader that uses the FontColor uniform. More... | |
| static PropertyType< float > | FontSizeProperty |
| Use the Font Size property to set the size of the font in device-independent pixels. More... | |
| static PropertyType< ResourceSharedPtr > | FontMaterialProperty |
| Use the Font Material property to set the material whose shader is used to render the text. More... | |
| static PropertyType< TextBlockConcept::TextHorizontalAlignment > | TextHorizontalAlignmentProperty |
| Use the Text Horizontal Alignment property to set the horizontal alignment of the text. More... | |
| static PropertyType< TextBlockConcept::TextVerticalAlignment > | TextVerticalAlignmentProperty |
| Use the Text Vertical Alignment property to set the vertical alignment of the text. More... | |
| static PropertyType< float > | LineSpacingProperty |
| Use the Line Spacing property to set the line spacing in multiples of the normal line height of the selected font. More... | |
| static PropertyType< float > | CharacterSpacingProperty |
| Use the Character Spacing property to set the character spacing in device-independent pixels. More... | |
| static PropertyType< string > | OverflowProperty |
| Use the Overflow property to set the characters that represent the clipped text when the text string to be rendered is too long to fit in the node. More... | |
| static PropertyType< string > | TextProperty |
| Use the Text property to set the text content that the text block renders. More... | |
| static PropertyType< bool > | WordWrapProperty |
| Use the Word Wrap property to break long text lines to multiple lines to make the text fit within the boundaries of the text block. More... | |
| static PropertyType< bool > | ConstrainContentHeightProperty |
| Use the Constrain Content Height property to cut out the last lines that do not fit within the boundaries of the text block. More... | |
| static PropertyType< float > | FixedCharacterWidthProperty |
| Use the Fixed Character Width property to override the font advance widths and make each character take a fixed amount of space specified in device-independent pixels. More... | |
| static PropertyType< Vector2 > | HorizontalPaddingProperty |
| Use the Horizontal Padding property to set the padding spaces between the content and the left and right boundaries of the text block. More... | |
| static PropertyType< Vector2 > | VerticalPaddingProperty |
| Use the Vertical Padding property to set the padding spaces between the content and the top and bottom boundaries of the text block. More... | |
| static PropertyType< bool > | RemoveSideBearingsProperty |
| Use the Remove Side Bearings property to position the leftmost characters of left-aligned text and rightmost characters of right-aligned text exactly within the boundary of the text block. More... | |
| static PropertyType< bool > | FractionalCharacterWidthProperty |
| Sets whether Kanzi uses fractional or rounded character widths to lay out text. More... | |
| static PropertyType< bool > | SnapCharacterToPixelProperty |
| Sets whether Kanzi positions characters in 2D rendering to the nearest pixel: More... | |
| static PropertyType< FontHintingPreference > | HintingPreferenceProperty |
| Sets the hinting preference of the selected font. More... | |
| Protected Types inherited from kanzi::Node2D | |
| enum | Node2DFlags { AllowClear, AllowRenderChildren, AllowRenderSelf, ForegroundIsTranslucent, ForegroundTranslucencyRequested, RequiresBackgroundQuad, RequiresExtract, ChildrenRequireExtract, Node2DFlagsBitCount } |
| Different Node2D flags for bit set. More... | |
| Protected Types inherited from kanzi::Object | |
| typedef vector< AppliedStyleEntrySharedPtr > | AppliedStyleContainer |
| Applied style container. More... | |
| Static Protected Member Functions inherited from kanzi::Node | |
| static VisitorResult | updateResourceVisitor (Node &node, const ResourceID &id) |
| static VisitorResult | updateAllResourcesVisitor (Node &node) |
| static VisitorResult | applyStylesVisitor (Node &node, bool apply) |
| static VisitorResult | attachVisitor (Node &node) |
| static VisitorResult | detachVisitor (Node &node) |
| static VisitorResult | validateDrawVisitor (Node &node) |
| Visitor for validating draw. More... | |
| static bool | processPropertyChanged (Node &node, AbstractPropertyType propertyType, const PropertyStoragePtr &nodePropertyStorage, AbstractPropertyTypeDescriptor::PropertyStorage *changedPropertyStorage, PropertyNotificationReason reason) |
| Processes notification handlers for node and property storage. More... | |
| static VisitorResult | propertyChangedVisitor (Node &node, AbstractPropertyType propertyType, AbstractPropertyTypeDescriptor::PropertyStorage *propertyStorage, PropertyNotificationReason reason) |
| Protected Attributes inherited from kanzi::TextBlockConceptImpl< Node2D, TextBlock2D > | |
| FontSharedPtr | m_cachedFont |
| Font resource reference. More... | |
| TextFormatSharedPtr | m_textFormat |
| The text layout for the glyphs that this node displays. More... | |
| ClassPropertyDefaultValue< ResourceSharedPtr > | m_classValueFontMaterialProperty |
| Default value for font material property. More... | |
| ClassPropertyDefaultValue< ResourceSharedPtr > | m_classValueFontProperty |
| Default value for font property. More... | |
| Protected Attributes inherited from kanzi::Node2D | |
| unique_ptr< NodeVisual2D > | m_visual |
| Visual information. More... | |
| unique_ptr< NodeCompositor2D > | m_compositor |
| Composition and caching information. More... | |
| QuadDescription | m_backgroundQuadDescription |
| Background clipping quad / composition quad description. More... | |
| ClippingArea | m_clipping |
| Clipping parameters. More... | |
| CompositionRequirements | m_compositionRequirements |
| Composition requirements for this 2D node. More... | |
| Protected Attributes inherited from kanzi::Object | |
| AppliedStyleContainer | m_appliedStyles |
| Listing of applied styles applied to this object. More... | |
Text Block 2D displays a small amount of text in 2D.
To create a Text Block 2D node:
To set the font of a text block:
To add the text shown by a text block:
To adjust the appearance of the text:
|
explicitprotected |
Constructor.
| domain | The UI domain the new node belongs to. |
| name | The name of the node. |
|
static |
Creates a TextBlock2D node.
| domain | The UI domain the new node belongs to. |
| name | The name of the node. |
|
static |
| KzcRectangle kanzi::TextBlock2D::getGlyphPosition | ( | size_t | index | ) | const |
Returns glyph rectangle of given index in layer space.
Node2D::measure() implementation.
Reimplemented from kanzi::Node2D.
|
protectedvirtual |
Node2D::arrange() implementation.
Reimplemented from kanzi::Node2D.
|
protectedvirtual |
Node2D::updateRenderOverride() implementation.
Reimplemented from kanzi::Node2D.
|
protectedvirtual |
Node2D::onAttached() implementation.
Reimplemented from kanzi::Node.
|
protectedvirtual |
Node2D::onDetached() implementation.
Reimplemented from kanzi::Node2D.
|
protectedvirtual |
Node2D::renderSelfOverride() implementation.
Reimplemented from kanzi::Node2D.
|
protectedvirtual |
Node2D::onNodePropertyChanged() implementation.
Reimplemented from kanzi::TextBlockConceptImpl< Node2D, TextBlock2D >.
|
protected |
Positions the text and prepares the rendering data.
|
protected |
Returns how much the text format needs to be translated so that it is positioned according to the alignment properties.
